This product is usually used as heavy-duty anti-corrosive coating for gas pipeline, sewage treatment pool, chemical plant equipment and pipeline. In addition to finish coating, this product can also be used as intermediate paint.
BJ320
IMS
Customized
Glossy
~1.3 Kg/L(after mixing)
27℃
Epoxy glass flake curing agent
100µm dry film thickness (about 200µm wet film thickness)
(23±2℃)7~15d
15~18Mpa
Part A: Part B= 20:5
(50±2 )%
Product Description
This product is a high solid two-component paint which is composed of modified epoxy resin, conductive metal powder, elastic polyamide curing agent, etc. In addition, this paint also needs to add wear-resisting fillers before use. Meanwhile, the paint film has excellent oil resistance, corrosion resistance, wear resistance and long-lasting anti-static effect.
Typical Uses
It is designed for walls, floors and storage tanks of the anti-static factories such as the electronic, microelectronic, communication and computer. Besides, the types of foregoing factories also include precision instrument, textile, printing, powder, etc.
Technical details
Color | Customized |
Gloss | Glossy |
Density | ~1.3Kg/L(after mixing) |
Hardness | Epoxy paint curing agent |
Solid Volume | (50±2 )% |
Film thickness | 100um dry film thickness (about 200um wet film thickness) |
Theoretical spreading rate | 3.8m⊃2;/Kg (100um dry film thickness) |
Full Cure | (23±2℃)7~15d |
Flash Point | 31℃ |
Drying Schedule
Substrate Temperature | 10 oC | 20 oC | 30 oC |
| To touch(100um) | 8h | 4h | 3h |
To handle(100um) | 48h | 24h | 4h |
Min. recoating time | 16h | 8h | 4h |
Max. recoating time | - | - | - |
Pot life | 1.5h | 1h | 0.5h |
Surface Treatment
a. Concrete grass-roots floor, first of all, must confirm whether the base surface concrete below whether there is a reliable moisture-proof facilities. New concrete or cement base at least 28 days of maintenance time, and its water content should not exceed 5%, using empirical methods to assess the water content of the base.
b. The grass-roots floor surface should be clean, solid and free of contaminants, such as mortar and paint sputtering, maintenance agents, grease, etc. For too much floating pulp, it is best to use light roughing, grinding. Oily ground, using electric angle grinder grinding.
c. The surface of the ground cracks, empty drums and other defects should be repaired and flat.
d. No matter what method is used to treat the surface, it must eventually be clean, solid and dry on the grass-roots surface. It is particularly important that the grass-roots level must not be in a state of rising moisture.
e. Grassroots clean-up, polished with a polishing machine.
Classical coating system
Epoxy Sealing Primer | 1*30µm (dry film thickness) |
Epoxy Putty | Epoxy Putty |
Anti-static Floor Paint | 100µm (dry film thickness) |
