H53-30
IMS
Custom color
1.6
≥ 40
36h
Mix part A and part B as 24:4 by weight.
| Availability: | |
|---|---|
Epoxy Zinc Phosphate Primer H53-30
| Epoxy Zinc Phosphate Primer Description
Epoxy Zinc Phosphate Primer H53-30 is mainly prepared by epoxy resin, ultra-fine zinc powder, and polyamide as curing agent. This product features:
● Sealing property | ● High adhesion |
● Extending substrate using life | |
● Excellent resistance to heat, rust and corrosion. | |
This heavy anti-corrosion primer provides a cathodic protection layer in a wide range of industrial situations as:
· Machinery&Engineering facilities | · Pipelines |
· Bridges & ships | · Steel structure |
A:24 kg B：4kg
Part A: 24 kg in a 20-liter iron barrel
Part B: 4 kg in a 6-liter iron barrel.
Appearance | Grey, rusty red, green, custom |
Density, kg/L | ~1.6 |
Volume solid, % | ≥ 40 |
Flash point, oC | 23 |
Mature period, h | 0.5 |
Pot life, h | 8 |
Theoretical spreading rate, kg/m2 @ 80µm dry film | 0.32 |
VOC, g/L | 420 |
Product | Thickness | |
Primer: | H53-30 Epoxy Zinc Phosphate Primer | 2*40 µm |
Midcoat: | H53-6 epoxy mica iron oxide paint | 150 µm |
Topcoat: | BS52-10 acrylic polyurethane finish paint | 2*40 µm |
About Us We are headquartered in Jiangsu, China, established in 2016, and our market reach extends to Southeast Asia (40.00%), Africa (15.00%), Eastern Europe (15.00%), Western Europe (10.00%), the Middle East (10.00%), North America (5.00%), and the Domestic Market (5.00%). Our team comprises approximately 51-100 dedicated professionals.
Ensuring the highest quality is our priority. We achieve this by: Conducting pre-production samples before mass production.
Carrying out thorough final inspections before shipment.
Our product range includes a variety of offerings such as Alkyd Paint, Polyurethane Paint, Epoxy Paint, Acrylic Paint, Organic Silicone Paint, and more.
There are several compelling reasons to opt for our products:We possess a rich 22-year history dedicated to the development, production, and sales of heavy anti-corrosion coatings.
We hold the prestigious designation as the developer for a military unit and are located within the Changzhou state high technology industrialization base for new paint.
Our commitment to quality is underscored by ISO9001, ISO14001, and OHSAS18001 certifications.
We offer the following services:Accepted Delivery Terms: FOB, EXW
Accepted Payment Currency: USD
Accepted Payment Type: T/T
Multilingual Support: English and Chinese
Feel free to reach out to us for all your coating needs, and we will be delighted to assist you.
ROHS
ISO 9001
SRC
CE
Mixing
Mix part A and part B as 24:4 by weight. Slowly add part B into part A and ensure mixed completely.
Thinner:
X-10 polyurethane paint exclusive thinner ≤ 10 % w./w.
Cleaner:
X-10 polyurethane paint exclusive thinner
Application method:
Airless Spray: Pressure : 1800 - 2700 psi ,Hose: 1/4" ID, Tip:.015" - .021".
Filter: 60 mesh.
Brush :. Nylon / polyester.
Roller:1/4 - 1/2" woven.
Application process:
Apply certain amount of sealing agent to further smooth surface of substrate with airless spraying or rolling.
Towel two layers of polyurethane slurry (a rough layer followed by a fine the layer) on the surface to required thickness. Before toweling second layer, smooth the first layer by grinding.
Grind the intermediate layer and clean up extra sands or quartz on intermediate layer, thereafter apply finish coat.
YMS Paint, one of famous trademarks in China, devotes to industrial paint research, production and sales since 2001.
Oriented by technology, we serve customers worldwide not only our high quality products, but also technical consultation and engineering scenarios. Cooperating with UNSW and BUCT, We invest millions to update our technology so that we can bring out better and cheaper products.
Our core products, including antirust paint, acid & alkali resisting paint, heat resisting paint, building & floor paint etc., help protect and extend substrate life for years.
