This product is usually used as heavy-duty anti-corrosive coating for gas pipeline, sewage treatment pool, chemical plant equipment and pipeline. In addition to finish coating, this product can also be used as intermediate paint.
BJ220
IMS
Customized
Glossy on rough surface
~1.2Kg/L(after mixing)
27℃
Epoxy glass flake curing agent
100um dry film thickness (about 167um wet film thickness)
(23±2℃)7d
15~18Mpa
Part A: Part B= 20:5
(60±2 )%
Product Description
This product is a two-component thick film topcoat based on epoxy resin, anti-rust filler, amine adduct curing agent. The paint film is tough, abrasion-resistant and has great impermeability, high mechanical strength and strong anti-seismic and crack resistance.
Typical Uses
This product is usually used as heavy-duty anti-corrosive coating for gas pipeline, sewage treatment pool, chemical plant equipment and pipeline. In addition to finish coating, this product can also be used as intermediate paint.
Technical details
Color | Customized |
Gloss | Customized |
Density | ~1.2Kg/L(after mixing) |
Hardness | ~1.2Kg/L(after mixing) |
Solid Volume | (60±2 )% |
Standard Film thickness | 100um dry film thickness (about 167um wet film thickness) |
Theoretical spreading rate | 5m⊃2;/Kg (100um dry film thickness) |
Full Cure | (23±2℃)7d |
Flash Point | 27℃ |
Drying Schedule
Substrate Temperature | 10 oC | 20 oC | 30 oC |
| To touch(75um) | 9h | 4h | 1h |
To handle(75um) | 16h | 8h | 4h |
Min. recoating time | 16h | 8h | 4h |
Max. recoating time | 10d | 7d | 5d |
Pot life | 6h | 4h | 2h |
Surface Treatment
All surface to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.
For bare steel, it shall be sandblasted to reach Sa2.5(iso8501-1:2007) standard. Depending on the environment of the non-immersed part, grinding with power tools is acceptable but shall at least reach St2(iso8501-1:2007) standard.
For shop primed steel, the shop primer shall be clean, dry and approved.
For surface painted coatings, this product can apply only to clean, dry and good compatible primer.
Classical coating system
Epoxy Glass Flake Anti-rust Paint | 2*100 µm (dry film thickness) |
Epoxy Glass Flake Finish | 2*50um (dry film thickness) |
Please inquire JIANBANG Paint for specific coating solutions. |
