FB-12
IMS
Custom color
1.4
27
55 ± 3
50
≥ 5
Mix part A and part B as 20:4 by weight.
0.13
Availability: | |
---|---|
Fluorocarbon PTFE Topcoat LG-56
| Fluorocarbon PTFE Topcoat LG-56 Product Description
Fluorocarbon PTFE Paint Topcoat LF-23 is mainly prepared by fluorocarbon resin, weatherable pigments, and isocyanate as curing agent. This product features excellent resistance to:
● Heat & humidity | ● Aging, weathering, UV |
● Impact | ● Abrasion |
● Oil & solvent | ● Chemical substances |
| Fluorocarbon PTFE Topcoat LG-56 Typical Uses
· Gas & oil storage tank | · Bridges |
· Shipyard | · Galvanized workpiece |
· Iron tower | · Chemical plants |
· Offshore platforms | · Petrochemical plants |
| Fluorocarbon PTFE Topcoat LG-56 Packaging
A:20kg B:4kg
Part A: 20 kg in a 20-liter iron barrel
Part B: 4 kg in a 5-liter iron barrel.
| Fluorocarbon PTFE Topcoat LG-56 Basic Technical Datasheet
Appearance | Custom color, glossy |
Density, kg/L | ~1.40 |
Flash point, oC | 27 |
Volume solid | ≥ 50% |
Fineness, µm | ≤ 35 |
Fluorine content | ≥ 20% |
Impact resistance, cm | 50 |
Hardness | F |
Adhesion, MPa | ≥ 5 |
Bending test, mm | 2 |
Resistance to water, 168h | No change |
Resistance to heat & humidity, 1000h | No peeling, blister and rust |
Resistance to salt spray test, 1000h | No peeling, blister and rust |
Resistance to acid (50g/L H2SO4),168h | No change |
Resistance to alkali (50g/L NaOH),168h | No change |
Theoretical spreading rate, kg/m2 | 0.13 |
@ 30 µm dry film | |
Pot life, h | 6 |
VOC, g/L | 420 |
Product | Thickness | |
Primer: | H06-1 epoxy zinc rich primer | 2*40 µm |
Midcoat: | H53-6 epoxy mica iron oxide paint | 150 µm |
Topcoat: | FB-1 Fluorocarbon paint | 2*40 µm |
ROHS
ISO 9001
SRC
CE
About Us We are headquartered in Jiangsu, China, established in 2016, and our market reach extends to Southeast Asia (40.00%), Africa (15.00%), Eastern Europe (15.00%), Western Europe (10.00%), the Middle East (10.00%), North America (5.00%), and the Domestic Market (5.00%). Our team comprises approximately 51-100 dedicated professionals.
Ensuring the highest quality is our priority. We achieve this by: Conducting pre-production samples before mass production.
Carrying out thorough final inspections before shipment.
Our product range includes a variety of offerings such as Alkyd Paint, Polyurethane Paint, Epoxy Paint, Acrylic Paint, Organic Silicone Paint, and more.
There are several compelling reasons to opt for our products:We possess a rich 22-year history dedicated to the development, production, and sales of heavy anti-corrosion coatings.
We hold the prestigious designation as the developer for a military unit and are located within the Changzhou state high technology industrialization base for new paint.
Our commitment to quality is underscored by ISO9001, ISO14001, and OHSAS18001 certifications.
We offer the following services:Accepted Delivery Terms: FOB, EXW
Accepted Payment Currency: USD
Accepted Payment Type: T/T
Multilingual Support: English and Chinese
Feel free to reach out to us for all your coating needs, and we will be delighted to assist you.
Mixing
Mix part A and part B as 20:4 by weight. Slowly add part B into part A and ensure mixed completely.
· Thinner:
X-7 Epoxy paint thinner
· Application methods:
Airless spray (recommended): Nozzle tip: 0.031-0.041 inch, pump: 45:1, pressure: 3600 psi minimum.
Brush: Nylon / Polyester natural bristle.
Roller: 3/8’’ – 1/2’’ woven with solvent resistant core.
IMS Paint, one of famous trademarks in China, devotes to industrial paint research, production and sales since 2001.
Oriented by technology, we serve customers worldwide not only our high quality products, but also technical consultation and engineering scenarios. Cooperating with UNSW and BUCT, We invest millions to update our technology so that we can bring out better and cheaper products.
Our core products, including antirust paint, acid & alkali resisting paint, heat resisting paint, building & floor paint etc., help protect and extend substrate life for years.
