Cold Galvanizing Paint

This product is a new environmental friendly heavy-duty anti-corrosive coating composed of metal zinc, composite high corrosive-resistant film-forming material and active assistant.It has the following resistance characteristics:

High adhesion	Rust resistance	Salt spray resistance
Weather resistance	UV resistance	Cathodic protection

Cold Galvanizing Paint Video

Cold Galvanizing Paint Basic Technical Datasheet

Color	Zinc gray
Gloss	No gloss
Density	~2.75Kg/L (after mixing)
Solid Volume	(45±2 )%
Standard Film thickness	80um dry film thickness (about 178um wet film thickness)
Theoretical spreading rate	2m²/Kg (80um dry film thickness)
Full Cure	(23±2℃)24h
Flash Point	33℃

Cold Galvanizing Paint Product Packaging Packaging: 25/30kg in a 20-liter iron bucket. Shelf Life: 12 months If exceeding shelf life, the products shall be tested before using.

Cold Galvanizing Paint Applicable Environment

Transmission tower	Substation	Communication tower	Scaffold
Bridge	Storage tank	Automobile chassis	Coastal facilities

Cold Galvanizing Paint Compatibility

	Product	Thickness
Primer:	Cold Galvanizing Paint	2*40 µm (dry film thickness)
Midcoat:	Cold Galvanizing Sealer	2*50 µm (dry film thickness)
Topcoat:	Cold Galvanizing Special Finish	2*30um (dry film thickness)

Cold Galvanizing Paint Finished Projects



Cold Galvanizing Paint Production Process

Cold Galvanizing Paint Instructions For Use

Substrate Treatment：

All surface to be coated shall be clean and dry. The surface shall be evaluated and treated according to ISO8504 standard.

For bare steel, it shall be sandblasted to reach Sa2.5(iso8501-1:2007) standard. Depending on the environment of the non-immersed part, grinding with power tools is acceptable but shall at least reach St2(iso8501-1:2007) standard.

For shop primed steel, the shop primer shall be clean, dry and approved.

For surface painted coatings, this product can apply only to clean, dry and good compatible primer.

Instructions for Use:

• Mixing:

Ready to use

• Thinner:

Special thinner for cold galvanizing paint

• Airless spray:

Nozzle tip: 0.025~0.031 inches

Spray pressure: 18~28Mpa

Thinner ratio:5~15% (by weight of paint)

• BrushRoller:

Recommended

Must achieve required thickness
